EspañolDRE OS-150 Surgical Drill and Microsaw System
DRE OS-150 Surgical Drill and Microsaw System
0 items are in your cart. View cart now.
Need Advice? Ask Our Experts!
(800) 462-8195
Description
Implantology, reconstructive and maxillofacial surgical motor system that is available with an assortment of drills, microsaws and contra angles
The powerful, user-friendly OS-150 Surgical Drill and Microsaw System is designed for general oral surgery, implantology, and many micro surgery procedures. Its sophisticated motor control provides smooth and precise power delivery in any speed range.
Features
- Large, illuminated display: Reduction to the essential. All treatment parameter are clearly shown and legibly on the large display
- Keyboard: Easy to navigate with the up and down button to change the respective values (torque and speed)
- Two selected programs for drilling and placing the implant
- 3 programs for drilling, cutting threads, screwing in the implants and placing the cover screw
- Automatic memorize parameters
- Calibration mode for contra angles
- Integrated pump system for cooling the instrument to prevent tissue damage
- Modern design – no sharp edges – easy to clean
- Irrigation pump: built in low noise peristaltic pump – easy to load
Specifications
General
- Voltage:100/115/230 Volt at 50 – 60 Hz
- Max. output power/motor torque: 120 W/6 Ncm
- Max. torque at the instrument: 70 Ncm, 20:1 Contra Angle
- Coolant flow rate: 1 – 100 ml/min
- Dimensions, W × D × H: 260/250/110 mm
- Weight, control unit: 2.8 kg
- Foot control: Vario foot pedal
- Pedal IP code: IPX8
- Motor:
- Attachment of instruments: ISO 3964 connector (DIN 13940)
- Motor Speed: 300-40,000 rpm
- Max. Motor torque: 6 Ncm
- Motor Cable Length: 2 m
- Peristaltic Pump:
- Max volumetric displacement of pump: 100 ml/min.
