Reacondicionado - Siemens 900C Ventilador
Este producto es muy dificil para encontrar o ya no está disponible de DRE, por favor vea la lista de productos relacionados abajo o pedir su experto de equipos para informacion sobre un producto similar disponible.
0 Los artículos están en tu carrito. Mirar Carrito ya.
¿Necesita asesoramiento sobre los equipos? ¡Pregunte a Nuestros Expertos!
(502) 244-6333
Descripción
El Siemens 900C es "un Servomecanismo" ventilador respiratorio disponible restaurado de DRE. El 900C es aplicable para adulto, uso pediátrico, e infantil. Esta unidad tiene la OJEADA incorporada electrónica. Los accesorios incluyen el humedecedor, el mezclador, apoyan brazo, recorrido, mangueras, y carro.
Especificaciones
Physical Weight & Dimensions
- Dimensions: 50 × 23 × 32 cm
- Weight: 42 lbs (19 kg)
Control Ranges
- Working Pressure: Up to 120cm H2O.
- Modes: Volume controlled, volume control with sight, pressure controlled, pressure support, synchronized intermittent mandatory ventilation (SIMV), SIMV+ pressure support, continuous positive airway pressure, manual ventilation.
- Present Inspiratory Minute Volume: .5 - 40 1/min, with sufficient working pressure
- Flow Pattern: Constant, accelerating or decelerating
- Respiratory Rate: 5-120 breaths/min
- Inspriatory Time: 20-80% of respiratory cycle
- Pause Time: 0-30% of respiratory cycle
- PEEP: 0-50cm H2O
- Upper Limit: 15-120cm H2O
- Trig Sensitivity: -20-0cm H2O (below PEEP)
- SIMV Rate: high rate (4-40 SIMV breaths/min), low rate (.4-4 SIMV breaths/min)
- Sight: double tidal volume possible every 100 breaths
- Compressed Volume: 0.075 1(internal)
Monitoring
- Analog Presentation:
- Airway pressure: -20 - 120 cm H2O
- Expired Minute Vol: Adults 0-40 1/min, infants 0-4 1/min
- Digital Presentations:
- Respiratory Rate: 5-120 breaths/min
- O2 Concentration: In % by volume, 20-100%
- Inspired Tidal Volume: 0-1999 mL
- Expired Tidal Volume: 0-1999 mL
- Expired Minute Volume: Adults 0-40 1/min, infants 0-4 1/min.
- Peak Pressure: 0-120 cm H2O
- Pause Pressure: 0-120 cm H2O
- Mean Airway Pressure: 0-12 0cm H2O
Gas & Power Supply
- Must fulfill specifications for medical gases.
- Gas Consumption: Approximately equal to preset inspiratory minute volume or equal to flow meter setting.
- Gas Supply via High Pressure Inlet: from central gas supply, compressor or gas cylinder.
- Electronic Gas Supply Unit, Inlet Pressure: 2.5-5 bar (250-500 kpa; 35-70 psi)
- Other Gas Supply Inlet Pressure: 2.5-7 bar (250-700 kpa; 35-100 psi).
- Gas Supply via Low Pressure Inlet: vial flowmeters
- Power Supply: (100), 110, 120, 220, 240, 50 or 60 hz
- Power Consumption: approximately 40 w
Alarms & Indicatators
- Push Button: Audible signals, muted for 2 min maximum.
- Alarms: Gas supply alarm, apnea alarm, expired minute volume, O2 concentration, upper pressure limit, power failure.
- Indicators: set minute volume alarm, set O2 alarm, set O2 alarm, pressure support, CPAP, MAN SIMV high/low rate, expired minute volume infants, patient trig.
Special Funtions
Inspiratory pause hold, expiratory pause hold gas exchange.
